DRAGON A400
Used for coping, multiple hole pieces, >2 routing centers, quality/tolerance requirement.
Maximum Length: 24ft
Maximum Weight: 400lb
Maximum Dimensions: Pipe 6″ OD, Rectangle 6×2, Square 5×5
Maximum Wall Thickness: 1/4″
Tolerance: Holes 1/32″ Wider Diameter
SAW
Used for single straight cuts & long pieces >20ft.
Maximum Cut Height: 19″
Maximum Cut Width: 18″
Maximum Cut Angle: 60° (range from 30° to 150°)
Maximum Wall Thickness: 1/4
PLASMA Hypotherm XPR300
Used for high speed & precise cuts, irregular shapes.
Maximum Thickness: 2″
Maximum Width: 10 ft
Maximum Length: 30 ft
Tolerance: Plasma outer wall dump body need 1/4″
1/16″ for size on size pins
PRESS Accurpress
Used to create formed parts.
Maximum Tonnage: 350 tons/45 tons a foot
Bed Length: 14′
Maximum Catch Length: 60″
Throat Depth: 14″
Distance Between Frames: 147″
*Make sure flange length is long enough for desired bottom die
Tolerance: ±1/16″ ±1°
SHEAR Accursheer
Used for Square or rectangular parts within max capacity.
Maximum Thickness: 1/4″
Maximum Length: 10 ft
Tolerance: ±1/16″ for length/width, ±1/8″ square
ROLLER MCS Davi
Used for parts that need a radius such as: cones, pipe, bucket liners & backing rings.
Roll Length: 10′ x 1/4″
Maximum 1″ Thickness @ 8″ MS
COIL
Used for All Kanban parts: studs, crossmembers, door crossmembers, door uprights, front load parts, I/S and O/S skirts.
SCS Coil Sizes:
11ga x 4.5, 6, 6.915, 8.093, 10.143, 16.929
3/16 x 11.242
IN-HOUSE CAD DESIGN SERVICES
In House Design Team
We have staff dedicated to meet your custom fabrication needs.
Latest Design Technology
Solid Edge ST6 with FEA (Finite Element Analysis)
Customized 3D Modeling
Examine your product with no material or fabrication costs.
